TX7 Intelligent Fire Alarm System

Home TX7 Intelligent Fire Alarm System TX7210 Addressable single Inpu...

TX7210 Addressable single Input-output Module

EN54-18:2005 Certified
Built-in MCU processor and digital addressing
24VDC/2A Output relay contact and control module
Input Fire or supervisory signal configuration
LED status indicator
Onsite Adjustable Parameter
Loop powered or external power supply
Surface mounting with fix base for simple installation

Get A Quote

Download Resources

Download Our Product Files

Download Brochure Download Datasheet

Description
Specifications
Cases
FAQ
Related Products

Technical Specifications

Approvals	LPCB / CE-CPR
Input Voltage	Loop Power: 24VDC [16V to 28V] External PSU: 20V to 28VDC
Current Consumption	Loop Standby: 0.6mA, Alarm: 1.6mA External PSU Standby: 0.6mA, Alarm: 45mA
Control Output Voltage	24VDC / 2A rating
Input Relay	Normally Open dry contact
Input Resistance	5.1 KΩ / ¼ W
Protocol / Addressing	T&A, Value range from 1 to 254
Indicator Status	Normal: Single blink / Active: Steady / Fault: Double Blink
Material / Colour	ABS / White Glossy finishing
Dimension (L×W×H)	108 × 86 × 38 mm
Weight	170g (with Base), 92g (without Base)
Operating Temperature	-10°C to +50°C
Ingress Protection Rating	IP30
Humidity	0 to 95% RH, Non-condensing
