Tanda

Hybrid Home Security System

Home Hybrid Home Security System TW3205 Wireless Water Sensor

TW3205 Wireless Water Sensor

Automatically detect whether the room, the warehouse, is soaked, can also be used as a water level alarm.
The terminal reports the event to the home fire alarm controller to form data statistics and alarm data collection.
Data transmission through Foslink, high real-time.
Adopt accurate ADC sampling inside the module to realize functions such as low power alarm and real-time power measurement.
Use low-power communication module to make the main module ultra-low standby current<30uA.
Suitable for private homes, warehouses, archives, water tanks and other applications that need to detect water levels.

Get A Quote

Download Resources

Download Our Product Files

Technical Specifications

Operating Voltage	DC 3V
Static Power	40μA
Alarm Current	<140mA
Indication and Operation	The module is equipped with a three-color status indicator and one base disengagement key
Installation Method	Sticking
Operating Temperature	-5°C ~ +40°C
Operating Humidity	0–95% RH, no condensation
Outline Dimension	75mm × 35mm × 23mm (excluding magnet)
Housing Color	White
Weight	About 50g
