TX3000D Fire Alarm Controller / Fire Fighting Linkage Controller

LCD display
The control panel is provided with 2.8 inch TFT LCD, clearly and intuitive. Various functions can be achieved by simple operation.
Provided with modular switching power supply
Modular switching power supply adopted by control panel has high switching efficiency, and is provided with main power supply and standby power supply change, and accurate charging and discharging management. In addition, over-voltage protection of input, short circuit protection of output, reversing protection and short circuit protection of standby power supply.
The equipment offers various communication functions and high expandability.
The control panel is equipped with CAN and RS485 communication interfaces, allowing users to choose different communication modules based on their requirements.

Get A Quote

Download Resources

Download Our Product Files

Technical Specifications

Main Power Supply	Rated operating voltage AC220V (range 187V ~ 242V), 50Hz, 90W
Maximum Operating Current	0.5A
Standby Power	12.8V 4Ah
Bus Voltage	DC24V
Load Capacity	Bus current ≤500mA
Maximum Capacity	1 loop, maximum 242 bus equipment can be connected
LCD	2.8 inch TFT LCD, 320×240 resolution
Printer	Mini type thermo-sensitive printer
Weight	1.9 kg
Outline Dimension (L×W×H)	311mm × 60mm × 251mm
Installation Hole Distance	Horizontal distance 270mm Vertical distance 215mm
Housing Ingress Protection	IP30
Operating Environment	Temperature: 0°C ~ +40°C Relative humidity ≤95%RH, without condensation
